Optical-fiber quality control and documentation with FiberDoc

FiberDoc is a OTDR analysis tool that creates an industry-accepted documentation of fiber optic links/cables.

Downloads

Download Product flyer

Visit the FiberDoc product page

The base license provides function for checking for problems at 3 sources:

• Assembly
• Measurement
• Material

There are numerous benefits with FiberDoc:

Device-independent platform for
quality control and documentation

Compatible with many measuring
devices

Industry-wide recognized
documentation format (measurement
reports)

Support for loop measurement

Export of results and
Excel macro for extended reporting

Large user community

The Professional Extension provides additional functions for more advanced quality control:

Calculation and display of the IEC
dynamic range and E-event for noise
(IEC 61746)

Attenuation uniformity analysis (IEC TS 62033)

Calculation and display of noise in dB
(separately for measuring fibers and
measuring section)

Calculation of the actual event dead
zones and check whether auxiliary
cursors (5-point method) are located
within the dead zones

Automatic testing of device parameters
and OTDR measurement quality
parameters (specification of limit
values)
• Pulse duration
• Measuring/distance range
• IEC dynamic range
• Noise reduction
• Dead zones and event cursors

Automatic check for duplicates
• within a cable project or within
a selected file folder

Create Main cable test-reports which are compliant with the ZTV-43 standard of the Deutsche Telekom.

Easy to create by click from a cable project

Input additional data

Save time and avoid typing mistakes

Ideal for testing factory-based measurements of newly delivered cables as part of Factory Acceptance Tests (FAT).

The following functions are available in this add-on:

• automated Attenuation uniformity analysis (IEC TS 62033) for all fiber files in a cable project
• additional test-report page in cable print
• support of color codes
  • IEC 60794-2,
  • DIN IEC 60304/DTAG,
  • EIA598-A,
  • IEC 60304
